| AGC | Sets voltage and power for steady signals like oscillation and sine curves after 0.6-1 seconds to -10 dB. Short pulses and normal program signals are not limited |
| Bandwidth | 100 to 5000 Hz ( ± 3 dB) |
| Connector | Screw terminal |
| Control | Treble control: 0 - +9 dB, potentiometer; Induction loop adjustment: 0 - 170 m², potentiometer |
| Coverage | 170 m² acc. to IEC 60118-4, single-loop, free field |
| Dimensions (WxHxD) (mm) | 295 x 64 x 205 (483 x 64 x 205 with 19‘‘ bracket) |
| Display | Mains connection: 1 green LED; Input level: 1 green LED; Induction loop power: 1 green LED |
| Distortion | < 1 % |
| Dynamic | > 70 dB |
| Fall time | 0,5 - 20 dB/s |
| Headphone out | Jack 6,35 mm |
| Input | IN 1 and 2: 0.5 mV-100 mV / 10 kΩ (mic.) alt. 25 mV - 4 V/ 10 kΩ (line) AGC, switchable phantom voltage, XLR connections; IN 3: 50 mV-10 V / 10 kΩ, RCA connection |
| Max. current | 60 A peak to peak of 1-5 ms, 4 A RMS @ 1 kHz |
| Max. voltage | 31 V peak to peak |
| Output | Monitoring output 0 dBm-RCA - headphones output : Jack 6.35mm |
| Poids (kg) | 3.6 kg |
| Power | 7 - 200 W |
| Power supply | 230 - 240 VAC 50 Hz |
| Protection | Passive : 10A fuse - Active protection against short-circuit |
| Rise time | 2 - 500 ms |
